Piping System&Piping Material Selection Training

DEVELOP Training Center menyelenggarakan Kelas Piping System&Piping Material Selection Training yang sangat berguna untuk melatih Anda dalam mendapatkan skill teknis diantaranya tentang cara:

• Membaca Drawing Piping System
• Piping Fitting
• Membuat Datasheet pipa
• Kalkulasi Piping Wall Thickness
• Piping Material Selection
• dll

Piping System&Piping Material Selection Training

DEVELOP menerapkan Syllabus Kelas Piping System&Piping Material Selection Training dengan tahap-tahap pembelajaran berkualitas sbb :

Sesi 1-2

Skill Focus:

• Piping System Overview
• Piping Applicable Standards&Codes Industri
• Pipe Fittings
• 90 Degree Elbow (Long Radius Elbow, Short Radius Elbow&Weld Mitered Elbow)
• 45 Degree Elbow (Weld Tee&Stub In)
• Reducer&Weld Cap
• Screwed & Socket Weld Fittings
• Piping Fitting
• Flange
• Flange Rating
• Flange Facings (Flat Face, Raised Face)
• Ring Type Joint
• Flange Type (Weld Neck Flange, Threaded Flange, Socked Weld Flange, Slip On Flange, Lap Join Flange, Reducing Flange, Blind Flange, Orifice Flange etc)
• Bolts&Gasket
• Valve
• Gate Valve, Globe Valve Angle Valve
• Check Valve, Ball Valve&Plug Valve
• Butterfly Valve
• Relief Valve&Control Valve
• Membaca Drawing Piping System
• Flow Diagram & Instrumentation
• Process Flow Diagram, Mechanical Flow Diagram&Utility Flow Diagram
• Piping Instrumentation (Gauges,Controllers,Alarms,Indicators&Recorder)
• Piping Symbols, Piping Code&Specification Classes
• P&ID Transposition
• Equipment Lay Out
• Plant Coordinate System
• Site Plans, Unit Plot Plan&Baterry Limits
• Equipment Location Drawing (Equipment Lay Out)
• Foundation Location Drawing
• Piping Drawing Index

Sesi 3-4

Skill Focus:

• Piping Isometric
• Piping Drafting Format
• Ketebalan Untuk Garis pada Gambar Isometric
• Dimensioning/Ukuran Piping (Face Of Flange, Branch Connection, Equipment Centerline, Pipe Instrument Connection, Vents, Drains&Welded Support)
• Pipe Branches
• Piping Material Specification Changes&Spool Size
• Piping Process Vent&Drain
• Piping Hydrotest Vent&Drain
• Piping Orifice Tappings&Weld Spacing
• Piping Bills Of Material (BOM)
• Vessel Trim Isometrics
• Membuat Datasheet pipa
• Kalkulasi Piping Wall Thickness
• Piping Material Selection Piping Material
• Carbon Steel Piping Material&Selection
• Alloy Steel Piping Material&Selection
• Stainless Steel Piping Material&Selection
• Copper Alloy Piping Material&Selection
• High Nickel Alloy Piping Material&Selection
• Titanum Piping Material&Selection
• Frp ( Fiberglass Reinforced Plastic ) Piping Material&Selection
• Pvc ( Polyvinyl Chloride ) Piping Material&Selection
• Hdpe ( High Density Poly Ethylene ) Piping Material&Selection
• Abs (Acrylonitrile Butadiene Styrene) Piping Material&Selection
• Lined Pipe
• Cast Iron (Besi Tuang) Piping Material&Selection
• Malleable Iron Piping Material&Selection
• Case Study

Piping System&Piping Material Selection Training

Materi Training dirancang khusus oleh para praktisi Project Engineers sesuai dengan experience dan solid knowledge  mereka dalam menangani project. Anda akan mendapat sharing ilmu langsung dari para praktisi yang berpengalaman bertahun-tahun.

Selama training, instruktur kami akan menggunakan kombinasi teori serta praktek langsung dengan studi kasus telah dipersiapkan yang menyerupai Proyek nyata.
